Manifolds
Tank Manifold Systems
Unique Welding & Fabricating is a Custom Manufacturer of Hose Reels, Tank Manifold Systems and Valves, we aim to deliver real world solutions to the industry we serve through dedication to innovation, quality and sustainability
Unique Welding & Fabricating Heavy Duty Hose Or Cable Reel Services.
Strength and Reliability for Tough Jobs:
At Unique Welding & Fabricating we specialize in heavy duty hose reel and cable reel solutions designed to handle the industry’s toughest challenges. Our heavy duty hose reels and cable reels are engineered for durability, efficiency and high performance, making them ideal for industrial, commercial, and large-scale applications.
What is a Hose and Cable Reel?
Reels are devices used in various industrial settings to efficiently store, dispense, and manage hoses and cables. These reels are designed to improve safety, organization, and convenience when handling hoses and cables for tasks such as fluid transfer, air compression, and other applications in industrial environments.
Aluminum Casted Fluid Path
Specializing in custom electric, hydraulic, manual, air and spring rewind reels from 1" to 4".
R4 Series 2"Fluid Path Hose Reel
R4 Series 2″ Fluid Path Hose Reels
For 1 1/2″ Through 2″ I. D. Hose
Outlet: 1 1/2″ or 2″ standard male / female NPT gooseneck threads. Other sizes and / or threads are easily accommodated, per specifications.
Inlet: 2″ straight Victaulic is standard. 2″ Victaulic x 90° is available at additional cost.
R7 Series Aviation Hose Reel
R7 Series 3″ or 4″ Fluid Path Hose Reels
(3″ or 4″ FLUID PATH) For 2″ to 4″ I.D. Hose
Outlet: 2″ to 4″ standard male / female NPT gooseneck threads. Other sizes and / or threads are easily accommodated, per specifications.
Inlet: 3″ or 4″ straight Victaulic. 3″ or 4″ Victaulic x 90 degrees ia available at extra cost.
R33 Series Fuel Delivery Hose Reels
For 1 1/4″ to 2″ I.D. Hose (INVERTED STYLE)
Outlet: 1 1/4″ to 2″ standard male / female NPT gooseneck threads. Other sizes and / or threads are easily accommodated, per specifications.
Inlet: 2″ Victaulic x 90º is standard. 2″ Victaulic x 1 1/2 ” NPTF straight (optional).
Single Wrap, Spring Rewind & Cable Reels
Specializing in custom electric, hydraulic, manual, air and spring rewind reels from 1" to 4".
R21000 Series Aviation Hose Reels
R21000 Series Single Wrap Reels (1″ to 3″)
This R21000 Series; single wrap hose reel is excellent for petroleum and aviation services.
Rewind: The R21000 Series has a wide selection of options in terms of reeling such as unique chain, direct drive or sprocket powered by A.C. or D.C. electric motor, compressed air motor or hydraulic motor. Whatever your application may require, whether it be electric powered reels or manual reels you can look to Unique Hosereels to supply it and suggest what we think is best based on your application.
R8 Series Retractable Hose Reels
R8 Series Retractable 1/2″, 3/4″, and 1″ Fluid Path Hose Reels
1/2″, 3/4″ or 1″ Fluid Path For 1/4″ through 1” I.D. HOSE
Inlet: 1/2″ up to 1″ Female/Male NPT 90º Swivel Joint.
Gooseneck: 1/2″ up to 1″ Female/Male NPT.
Rear Position: You must specify roller position BW, VW or TW. If roller position is not specified, reels will be shipped with rollers in POSITION BW.
RC21 Series Cable Reel
Welded steel frame providing exceptional durability.
Spool assembly is fabricated from heavy gauge steel and rolled head edges for added strength and safety.
Bearings self-lubricating and self-aligning, requiring little maintenance.
Slip rings available – require the gauge of the cable, how many conductors, voltage and amperage and weight of cable to be able to meet your requirements.
Static Grounding & Custom Reels
Specializing in custom electric, hydraulic, manual, air and spring rewind reels from 1" to 4".
UGR50-100 Static Grounding Reel
UGR50-100 Series Hand Rewind Static Grounding Reels
Aluminum and Stainless Steel available
Static grounding reels provide for the payout, retraction and compact storage of 50 and 100 feet of static grounding cable, use in any flammable atmosphere when a build-up of static electricity could cause a spark and subsequent explosion, they operate manually by hand or with a spring re-wind mechanism requiring minimal cable pull to release the lock. A declutching arbor on the spring models automatically disengages the spring to prevent damage from reversing winding.
Series UGR can be supplied with or without 3/32″ diameter galvanized carbon steel aircraft cable X3/16″ OD, clear PVC cover & “Y” bracket
R8 Series Retractable Hose Reels
R8 Series Retractable 1/2″, 3/4″, and 1″ Fluid Path Hose Reels
1/2″, 3/4″ or 1″ Fluid Path For 1/4″ through 1” I.D. HOSE
Inlet: 1/2″ up to 1″ Female/Male NPT 90º Swivel Joint.
Gooseneck: 1/2″ up to 1″ Female/Male NPT.
Rear Position: You must specify roller position BW, VW or TW. If roller position is not specified, reels will be shipped with rollers in POSITION BW.
RC21 Series Cable Reel
R8 Series Retractable 1/2″, 3/4″, and 1″ Fluid Path Hose Reels
1/2″, 3/4″ or 1″ Fluid Path For 1/4″ through 1” I.D. HOSE
Inlet: 1/2″ up to 1″ Female/Male NPT 90º Swivel Joint.
Gooseneck: 1/2″ up to 1″ Female/Male NPT.
Rear Position: You must specify roller position BW, VW or TW. If roller position is not specified, reels will be shipped with rollers in POSITION BW.
Why Do I Need A Reel?
A reel is used to efficiently wind up and store a hose or cable – this creates a safer workplace and allows for a more efficient and easier workflow.
- The efficiency of a reel is in the storage of your hose or cable, which ensure its readily available in any environment its needed.
- A reel helps keep your hose or cable neatly wound and stored, preventing tangles and kinks. This makes for an organized and neat workspace and also ensures that your hose or cable is always ready for use without the hassle of unraveling knots.
- Hose and Cable reels are great for space saving; by mounting the hose or cable reel on a wall or placing it on a stand, you free up valuable floor space. A reel keeps your hose or cable off the floor to avoid tripping and other workplace accidents that may cause work stoppage or costly insurance issues.
When it comes to demanding environments, standard reels just won’t do. Unique’s reels are built with durability and reliablity, thats why our heavy-duty hose reel and cable reel becomes necessary. These robust reels are built to withstand extreme conditions, wheter you are dealing with high pressure, corrosive materials, or frequent use. Our team at Unique Welding & Fabricating is dedicated to providing you with exceptional heavy duty hose reel and cable reel services, ensuring reliability and performance you can count on.
Taking On The Industry's Toughest Reel Challenge!
We produce a broad range of custom products, and we’re a leader in scores of markets, with industrial custom designed and engineered built hose and cable reels, petroleum products and manifolds..
